VLF Sinus 45 kV

45 kV sine waveform VLF cable test system

• Test capacity of up to 10jJF - that's up to 40 km of cable at reduced frequency
and voltage

• Internal tano option with automatic results interpretation
• One minute burn after fault detection
• Automatic frequency adjustment based on cable length
• Adjustable DC pulse rates of 1:3 and 1:4
• IEEE compliant withstand testing for new installations up to 25 kV
• IEEE 400.2 compliant maintenance testing up to 35 kV
• IEC 60229 compliant sheath testing up to 20 kV DC

ORDERING INFORMATION

Item Cat. No.
VLF Sinus 45 kV 128300045
Internal tanDelta 138316309
Upgrade internal tanDelta (retroactive) 138316310

VLF Sinus Wave 54 kV 11III1111111111
\\\\\\111111111
54 kV sine waveform VLF cable test system

• High test capacity of 5 jJF
• Single-button operation "easyGo"
• Continuous duty cycle
• Integrated safety system
• Suitable for diagnosing 45 kV rated cables

Tan Delta

VLF system accessory

• Very accurate measurement
• Optional leakage current correction
• High wireless range
• Measurement at high voltage potential
• Light and portable
