3MTM Performance Plus Wire Connectors
Because of their increased wire range,just three 3MTM Performance Plus Wire Connectors handle the work of eight standard connectors. 0/8+ replaces the
orange, blue and gray wire connector style connectors, as well as 70% of the yellow wire connector and wing style connectors. R1Y+ replaces both red and
yellow wing style connectors. B/G+ covers both the large blue and gray connectors.
This simplifies selection of the right connector for a wide range of wiring jobs.There's also less inventory to manage, and a better chance you'll have the
connector you need to do every job.
A Better Bite for a Better Connection. 3MTM Performance Plus Wire Connectors 0/8+, R1Y+ and B/G+ now have a better bite.Wires feed into the
connector more easily, improving the security of the connection and increasing the level of pull out.
New Design Allows Easier Installation. We have modified the internal design of the O/B+, R1Y+ and B/G+ wire connectors. Installation is smooth,fast and
easy on the hands.
Flexible Skirts Provide Safety. The flexible skirts on the 0/8+, R1Y+ and B/G+ wire connectors make the workplace a safer environment. The flexible skirt
provides protection against potential shock situations.
Connection Type Wire
Connector Style Twist On
Flame Retardant Yes
600 V(1000 Vin signs, lighting fixtures
Maximum Voltage Rating and luminaries)
Operating Temperature 221°F (105°C)
RoHS 2011/6S/EU No
B/G+BOX BlG+JUG OIB+BOX OIB+JUG
054007-43152
054007-43150 054007-43151 054007-43153
Blue/Gray Blue/Gray Orange/Blue OrangelBlue
22- 12AWG 22- 12AWG
14~AWG 14~AWG 500
100 10,000
50 250 1000
500 2000 RIY+KEG
051128-57943
RIY+BOX RIY+JUG RedIYeJlow
22-8AWG
054007-43154 054007-43155
RedIYeJlow RedIYeJlow 17,000
22-8AWG 22-8AWG
100 500
1000 4000
3MTM Wire Connectors for Residential
Specifically created for the residential markets,the TIR+ replaces the yellow, tan and red connectors in the majority of field applications.
TIY+ replaces the yellow, orange, blue and gray wire nuts in most applications. Use the 412 (tan) connector for wire combinations from 2 #20 to
3 #10 AWG. This simplifies selection of the right connector for a wide range of wiring jobs. There's also less inventory to manage, and a better
chance you'll have the connector you need to do every job.
Connection Type Wire
Connector Style Twist On
Flame Retardant Yes
Maximum Voltage 600 V(1000 Vin signs, lighting fixtures and luminar-
Rating ies)
Operating Temperature
221°F (105°C)
RoHS 2011/65/EU No
