Tektronix®
/
Thklronp' fHS 12028-t:1J1 ....a 88 ~ 6 Product Highlights
Enabling Teaching ®,l Q @@b
I • Two channel instruments
• Integrated courseware feature - perform labs directly
®~
on the oscilloscope
0 G • Autoset enable/disable capability
• Included PC editor tool for easy lab creation
08 • Up to 2 GS/s sample rate on all channels
• Dual channel frequency counters
08 ~"' 0 ( 3 • 34 automated measurements and FFT analysis
-n fu e The Courseware Resouroe
Center is an interactive,
(J mu~i-ling ual website where
educators can share lab
@ @i material and ideas.
TBS1000B-EDU Series The FFT function can
show both frequency and
Meet the world's first dedicated teaching oscilloscope; the TBS1 OOOB-EDU. Not only time domain waveforms
does it deliver the performance you expect to see in a Tektronix scope; it also comes with simultaneously.
an innovative courseware feature that allows students to review lab material, perform step
by step instructions and document results, all on the oscilloscope. We couldn't make
engineering easier, so we made it easier to teach and learn .
Models .i . . . . Analog Bandwidth Analog Sample Rate
(per channeO
1BS1052B-EDU 50 MHz 1 GS/s
TBS1072B-EDU 70 MHz 1 GS/s
TBS1102B-EDU 100 MHz 2 GS/s
TBS1152B-EDU 150 MHz 2 GS/s
TBS1202B-EDU 200 MHz 2 GS/s
Recommended Probes Recommended Probes Another Product for Consideration
Passive Voltage Probes Current Probes Need more analysis features? The TBS1000B
models offer the same great performance and include
Tf'P0201 10X, 200 MHz, 300 V P602 1A 60 MHz, 10.6 A Trendplot'M, data logging and limit test capability.
CAT II RMSl250 A Peak/10
mAMin Ships with Product
Tf'P0101 10X, 100 MHz, 300 V
CAT II • Two TPPOxx1 200 MHz, 100 MHz or 50 MHz, Passive
P6022 120 MHz, 4 A Probes
RMSl1 00 A Peak/1
Tf'POO51 1OX, 50 MHz, 300 V mAMin • Certificate of Calibration
CAT II • CD with Customer Documentation
• Education CD with Course Editor SW and Lab
P2220 1OXl1 X, 200 MHzl6 A62 1 5 Hz to 50 kHz, 1000 A
A622 RMSl2oo0 A Peak/10 Examples
MHz , 300 V CAT 11/150 mAMin • Installation & Safety Manual
V CAT II • Power Cord
100 kHz, 100 A ocm • 5-year Warranty
High Voltage Probes
A RMS/ 100 A Peakl10
P5200A 5OOXl50X, 50 MHz, mAMin
± 1300Vl± 130V
P5100A 1OOX, 500 MHz, Recommended Accessories
P6015A 2500 V Peak
TEK- GPIB-to-USB converter
1000X, 75 MHz, USB-488
20 kV Peak
AC2 100 Soft Carrying Case
