Thktroni" TPS 20248 Product Highlights
• 10x oversampling on all channels
• 4 isolated analog channels
• 11 automated measurements and FFT analysis
• Optional power analysis software
~ • \ _ '. .. • ... • , to • • , Safely and easily make
floating measurements w~h
I the four isolated channels.
---.e J:O 0 Battery pack gives you
- up to 4 hours of portalble
operation. Hot-swap the
TPS2000B Series pack for 4 more hours!
Great performance goes beyond the lab. Make floating or differential measurements with
up to four isolated channels. Tackle challenging environments with backlit buttons and
optional power analysis software. Capture signals with Digital Real-Time Sampling.
Models Analog Channels Analog Bandwidth Analog Sample Rate
TPS2012B 2 100 MHz 1 GS/s
TPS2014B 4 100 MHz 1 GS/s
TPS2024B 4 200 MHz 2GS/s
Application Modules Recommended Probes Another Product for Consideration
TPS2PBND2 TPS2PWRl Module Passive Voltage Probes For very accurate power measurements, the PA1000
and Four P5122 Power Analyzer offers 0.05% basic accuracy.
Probes TPP0201 lOX, 200 MHz, 300 V
CAT II Ships with Product
TPS2PWRl Power Measurement
and Analysis Module TPP010l lOX, 100 MHz, 300 V • One TPP01 01 100 MHz, 10X Passive Probe Per
CAT II Analog Channel (TPS2012B & TPS2014B)
P2220 lOx/lX, 200 MHzl6 • One TPP0201 200 MHz, 10X Passive Probe Per
MHz, 300 V CAT 1111 SO Analog Channel (TPS2024B)
Recommended Accessories V CAT II
• OpenChoice'" Desktop and NI LabVIEW
1103 TEKPROBE Power SignalExpress'· TE (LE version) Software
Supply
High Voltage Probes • RS-232 to USB Adapter Cable
• One Lithium-Ion Battery with 4-hour Battery Life
AC2 100 Soft Carrying Case P5150 SOX, 500 MHz, 2S00 • Calibration Certificate, Quick Reference Manual,
V Peak, 1000 V RMS
TPSBAT Additional Uthium-Ion CAT II & Documentation on CD
Battery Pack (one • Front Panel Cover, AC Adapter with Power Cord
included standard w~h P5122 l00X, 200 MHz, • 3-year Warranty
instrument) 1000 V RMS CAT II
TPSCHG External Battery Current Probes
Charger
P6021 A 60 MHz, 10.6 A
RMS/2SO A Peakll0
Recommended Service rnA Min
SILV200 5-year Extended P6022 120 MHz, 4A
Warranty RMS/l00 A Peakll
rnA Min
A621 5 Hz to 50 kHz, 1000 A
RMS/2000 A Peak/l0
rnA Min
A622 100 kHz, 100 A DC171
A RMS/l 00 A Peakll0
rnA Min
TCP2020 SO MHz, 20 A DC/20
A RMS/1 00 A Peakl10
rnA Min
