UKE ®
820-2 LED Stroboscope
Rugged, easy-to-use, high intensity LED
Stroboscope for stop motion diagnostics
The Fluke 820-2 LED Stroboscope is a simple, easy to use tool to stop motion for
measurement and diagnostic purposes.
Investigate and observe potential mechanism failure with confidence on a variety
of machinery, in a wide range of industries, without making physical contact with
the machine.The Fluke 820-2 LED Stroboscope is a rugged, compact, portable
strobe with high intensity LED head, ideal for stop motion diagnostics, mechanical
troubleshooting, and process or product research and development.
Key features: Common applications for the 820-2
• High intensity 7-LED array-4,800 Lux The Fluke 820-2 LED Stroboscope is more
than just a tool to measure rotational
@ 6,000 FPM/30cm speed of machinery without physical
contact. It is also an excellent diagnostic
• High efficiency LED solid-state tool for a wide variety of applications:
light source with uniform flash
characteristics allow for higher flash • Identify belt wear of belt driven
rates-30-300,000 FPM (flashes per machines
minute)
• See product tags or markers
• Digital pulse width modulation for • Detect pulley wear and damage
exceptionally sharp images at high • Inspect condition of rotor blades,
speeds bearings and couplings
• Rugged, durable design utilizes solid- • Make belt slip visible
state LEDs with no filaments, gases,
hollow cavities, or glass-tone meter
drop)
• Quartz-accuracy control system
provides high accuracy-{).02 %
(± 1 digit)
• Multi-line LCD display
• Check the rotating speed of machinery
without physical contact or need for
reflective tape
• Advance or retard flash timing for
viewing gear teeth, cutting surfaces,
repeats, or "drifting" equipment.
• Simple push button operation with 2x
and .,.2 buttons for easy adjustment
Auke820-2
Mechanical specifications Specifications
Size WxL
Weight 5.71 x 6.09 x 19.05 em
Flash frequency 0.24 [kg]
Range
30 - 300000 FPM
Light 0.5 - 5000Hz
Color
Emission output A rox 6500K
4,800 1x@6000 FPM at 30[em]
Included Accessories
Protective case, external trigger connector
Ordering Information
Fluke 820-2 LED Stroboscope
282 www.tech-equipments.comlsales@tech-equipments.com
