/" 1"l..U.(.:'tv.aXs VERSN DSX-SOOO CableAnalyzer'"
~~ _ 051H'01J6J90R.n The DSX-5000 CableAnalyzer improves the efficiency of copper certification with unmatched speed for
testing Cat 6A and Class F' while meeting draft IEC Level V-the most stringent accuracy requirement.
2..111 1124T03lIlIC20 PASS The ProjX Management System ensures jobs are done correctly the first time and helps track progress
from set-up to systems acceptance. Taptive user interface troubleshoots faults faster by graphically
WIRE MAP ~ indicating the source of failures including crosstalk, return loss, and shield faults. Analyze test resu lts
and create professional test reports using LinkWare"" Cable Test Management Software.
Fluke Networks' DSX-5000 CableAnalyzer is Intertek (ETL) Verified in accordance with the IEC 61935-1
specifications for accuracy Level IIIe, IV, and draft Level V, and in accordance with the ANSIjTIA-1152
specifications for Level IIIe.
Versiv"" modular design supports copper certification, fiber loss, OTDR testing and
Ethernet troubleshooting
Taptive"" user interface simplifies set-up, and eliminates errors
Analyze test results and create professional test reports using LinkWare Cable Test
Management Software
Endorsed by more than 23 cabling manufacturers worldwide
Alien Crosstalk testing capability included
Model
DSX-5000
DSX-5000 120/GLD Kit bundled with 1 year of Gold Support coverage (available in the United Included in Bundle
States, Europe and Japan only. Europe order: DSX-5000 INTL/GLD, Japan order:
DSX-5000 AP/GLD)
DSX-5000QI DSX-5000 CableAnalyzer with CertiFiber Pro Quad OLTS Modules, and USB Video GLD-DSX-5000QI GLD3-DSX-5000QI
Inspection Probe for Copper and Fiber Loss certification
Kit bundled with 1 year of Gold Support coverage (available in the United
DSX-5000QI 120/GLD States, Europe and Japan only. Europe order: DSX-5000QiINTL/GLD, Japan order: Included in Bundle
DSX-5000Qi AP/GLD)
Model Descriptfon Gold 1YR Gold 3YR
DSX-5000QOI DSX-5000 CableAnalyzer with CertiFiber Pro Quad OLTS modules, OptiFiber Pro GLD-DSX-5000QOI GLD3-DSX-5000QOI
Quad OTDR module and USB Fiber Inspection Video Probe for Copper, Fiber Loss,
and OTDR certification
DSX-5000QOI120/GLD Kit bundled with 1 year of Gold Support coverage (available in the United Included in Bundle GLD3-DSX-5000MI
DSX-5000MI States, Europe and Japan only. Europe order: DSX-5000QOiINTLGLD, Japan order: GLD-DSX-5000MI
DSX-5000QOi AP/GLD)
DSX-5000 CableAnalyzer CertiFiber Pro Multimode MM om Modules and USB
Video Inspection Probe for Copper and Mulitmode Fiber Loss certification
Kit bundled with 1 year of Gold Support coverage (available in the United
DSX-5000MI120/GLD States,Europe and Japan only. Europe order: DSX-5000MiINTL/GLD, Japan order: Included in Bundle
DSX-5000Mi AP/GLD)
DSX-5000NTB DSX-5000 CableAnalyzer CertiFiber Pro Quad OLTS Modules, OptiFiber® Pro Quad GLD-DSX-5000NTB GLD3-DSX-5000NTB
OTDR Module, OneTouch AT Module, and USB Fiber Inspection Video Probe for
Copper and Fiber Cabling Certification and Network troubleshooting
Kit bundled with 1 year of Gold Support coverage (available in the United Included in Bundle
DSX-5000NTB120/GLD States, Europe and Japan only. Europe order: DSX-5000NTB INTL/GLD, Japan
order: DSX-5000NTB AP/GLD)
DSX-ADD-R 1 Versiv Remote, (2) DSX-5000 CableAnalyzer Modules, and accessories to add GLD-DSX-ADD-R GLD3-DSX-ADD -R
DSX-5000 CableAnalyzer capability to an existing OptiFiber Pro
DSX-CFP-Q-ADD-R 1 Versiv Remote, (2) DSX-5000 CableAnalyzer modules, (2) CertiFiber Pro Quad GLD-DSX-CFP-Q- GLD3-DSX-CFP-Q-
OLTS Modules, and accessories to add DSX-5000 CableAnalyzer and CertiFiber Pro ADD-R ADD-R
capabi lity to an existing OptiFiber Pro OTDR
DSX-ADD (2) DSX-5000 CableAnalyzer Modules, and accessories to add DSX-5000 GLD-DSX-ADD GLD3-DSX-ADD
capability to an existing CertiFiber Pro OLTS
288 www.tech-equipments.comlsales@tech-equipments.com
