P. 298
Copper Adapters, Accessories and Gold Support cont.
DTX-GG45-KIT GG45 Adapter Kit
DTX-TERA TERA Adapter Kit-Includes TERA Channel Adapters (2) and TERA Permanent Link
Adapters (2) to test Siemon TERA class F systems
DTX-PLA011 One (1) TERA Permanent Link Adapter for Siemon TERA Class F and Fa Systems.
Note: You will need at least one (1) DTX-CHAD11 adapter as well
DTX-CHAD11 TERA Channel Adapter for Siemon TERA Class FSystems
DTX-CHA002 Cat 6A/Class Ea Channel Adapter optimized for Alien Crosstalk measurements.
This adapter can be used to test Cat 6A/6/ 5e/ 5/3 and Class Ea/E/D and Cchannels
Personality Modules
DSP-PM19B SYSTIMAX(!) VisiPatch (!) 360 (T568B) Personality Module
DSP-PM19A SYSTIMAX VisiPatch 360 (T568A) Personality Module
DSP-PM17B TYCO/AMP 610XC Connector (T568B) Personality Module
DSP-PM17A TYCO/AMP 610XC Connector (T568A) Personality Module
DSP-PM16B LEVITON 110 (T568B) Personality Module
DSP-PM16A LEVITON 110 (T568A) Personality Module
DSP - PM15B ADC/KRONE Highband (T568B) Personality Module
DSP-PM15A ADC/KRONE ULTIM8 (T568B) Personality Module
DSP-PM14B ADC/KRONE ULTIM8 (T568B) Personality Module
DSP-PM14A ADC/KRONE ULTIM8 (T568A) Personality Module
DSP-PM13B SIEMON S210 (T568B) Personality Module
DSP-PM13A SIEMON S210 (T568A) Personality Module
DSP- PM12B PANDUIT GIGAPUNCH (T568B) Persona lity Module
DSP-PM11B Belden GigaBIX (T568B) Personality Module
DSP-PM11A Belden GigaBIX (T568A) Personality Module
DSP-PM10B SYSTIMAX 110 (T568B) Personality Module
DSP-PM10A SYSTIMAX 110 (T568A) Personality Module
DTX-SFM2
DTX-SFM2 DTX Singlemode Fiber Modules-Includes two modules (one for Main and one for Smart
Remote). each module contains 1310 nm and 1550 nm laser light source combined into
single output port, 850-1550 nm power meter, integrated VFL, SC adapter for power
meter and Singlemode SC-SC Test Reference Cords
GLD-DTX-FIBERMOD 1 year of Gold Support coverage for one DTX fiber module set- Models: DTX-MFM2,
DTX-GFM2 or DTX-SFM2
GLD-DTXFMOD-3YEAR 3 years of Gold Support coverage for one DTX fiber module set-Models: DTX-MFM2,
DTX-GFM2 or DTX-SFM2
DTX-EFM2
DTX-EFM2 Set of two DTX Encircled Flux Multimode Fiber Modules, each incorporating: 850 nm and
1300 nm LED sources combined into a single output port Set of Encircled Flux compliant
test reference cords(EF-TRC) 850/1300/1310/1550 nm power meter Integrated VFL.
GLD-DTX-EFM2 1 year of Gold Support coverage for one DTX Encircled Flux MM fiber module set-
Model: DTX-EFM2
GLD3-DTX-EFM2 3 years of Gold Support coverage for one DTX Encircled Flux MM fiber module set-
Model: DTX-EFM2
NFA-LC Set of two LC Adapters for DTX-xFM2 power meter port
NFA-ST
NFA-FC Set of two ST Adapters for DTX-xFM2 power meter port
NFBl/2-LC/ST FC Test Adapters, Set of two
A kit containing the Test Reference Cords sets NFK1-DPLX-LC, NFK1-DPLX-ST,
NFK2-DPLX-LC, NFK2-DPLX-ST, LC and ST adapters for the power meter and 62.5/125
and 50/125
292 www.tech-equipments.comlsales@tech-equipments.com
