JackRapid'· Termination Tool
The JackRapid termination tool is the industry's most innovative and time-saving insta llation tool.
JackRapid allows you to terminate jacks eight times faster than traditional impact tools-with accuracy
that's unmatched. The patented jack termination tool seats and terminates all wires simu ltaneously
with one squeeze of an ergonomic hand le. The built-in blade cuts off the excess wire after it is seated
in the connector, eliminating the need for a secondary trim step. Simple, one-handed operation reduces
hand fatigue. With JackRapid, you'll never punch into the palm of your hand or through drywall again.
Cuts installation time-easy-to-use handle, seats and cuts all wires at once, saving you up to two
minutes installation time per jack
High-quality, consistent terminations-no more compromised connections and wasted jacks
Simple, one-handed operation with an ergonomically designed handle reduces hand fatigue
Model Description
JR-LEV-1 JackRapid termination tool (for Leviton 41106, 41108, 5G108)
JR-LEV-1-H JackRapid replacement blade head (for Leviton 41106, 41108, 5G108)
JR-SYS-UNI-1 JackRapid termination tool (for Systimax MPS100E, C5,M1BH and Uniprise UNJ600j500j300)
JR-SYS-UNI-1-H JackRapid replacement blade head (for Systimax MPS100E, C5, M1BH and Uniprise UNJ600j500j300)
JR-LEV-2 JackRapid termination tool (for Leviton 61110, 5G110, 6110G)
JR-LEV-2-H JackRapid replacement blade head (for Leviton 61110, 5G110, 6110G)
JR-SYS-2 JackRapid termination tool (for Systimax MGS400, MGS500, MFP420, MFP520)
JR-SYS-2-H JackRapid replacement blade head (for Systimax MGS400,MGS500, MFP420, MFP520)
JR-ORT-2 JackRapid termination tool (for Ortronics TJ5EOO, TJ600, TJ610)
JR-ORT-2-H JackRapid replacement blade head (for Ortronics TJ SEOO,TJ600, TJ610)
JR-ADC-2 JackRapid termination tool (for ADC KM8, Copper Ten!!»
JR-ADC-2-H JackRapid replacement blade head (for ADC KM8, Copper Ten)
JR-ERGOHANDLE JackRapid ergonomic handle
JR-PAN-2 JackRapid termination tool (for Panduit NK688M)
JR-PAN-2-H JackRapid replacement blade head (for Panduit NK688M)
To learn more visit : www.flukenetworks.com/jackrapid
Get accurat e terminations and clean, consistent cuts every time with t he JackRapid Termination Tool.
1. Strip cable jacket with a standard cable 2. Determine wiring scheme. Dress 3. Insert jack in JackRapid front first with
stripper or the built-in cable stripper. all four pairs (eight wires). IDC slots facing blades of JackRapid.
4. Ensure jack is completely and securely 5. Pull trigger completely and remove 6. Wires will be seated and cut for
inserted in jack holder bed with IDC excess wire prior to re leasing trigger. a solid termination.
slots facing the blades.
