lEG short-circuiting and earthing IEC61230
systems for MV substations
is
Installation on bare conductors

Reference Rating Installation on Composition Connection set
MT-5805 (kAl1 s) fixed points
MT-8408
MT-9801 • 05-35 3 clamps MT-815-C 3 cables 95 mm2 Contact clamps.

20 - 16-40 1 MT-840/1 1 earth cable 35 mm2

I 5-40

. 018-33 3 clamps MT-814/3 3 cables 70 mm2

12,5 1 MT-840/1 1 earth cable 35 mm2

• 05-16 3 clamps MT-817-C 3 cables 50 mm2
10 - 0-16 3 clamps MT-81412 1 earth cable 25 mm2

• 05-28 1 MT-84011

Delivered in case.

Installation on pennanent fixed points

Reference Description 3 copper cableextra-flexible
MT-890 Clamps 3 claws siliconesheath. L: 1.5 m.
MT-891 Earth clampfixation
MT-893 Cable tensioner 1 trifurcation
MT-895 Cable kit support connector earthed
CI-06-D Wall mounted support by an extra-flexible
copper cable with
silicone sheath,

L= 2.5 m.

Earth clamp.

Extra-flexible cable

silicone sheath.
L: 2.5 m.

Insulating stick to be
ordered separately.

Plastic case CE-4-21-C
included.
535
