P. 829
~FLIR
Specifications
FLIR MR176: Imaging Moisture Meter
Imaging Detector FUR Lepton microbolometer
Image Calibration Automatic with manual lock scale option
Thermal Image Resolution (W x H) 4800 pixels (80 x 60)
Spectral Response 8to 1 4~m
Field of View (W x H) 51 ° x38° Color Display
Laser
Sensitivity < 150mK
19.7in' (49cm' )
Detection Limit
(Wet Area Detection @ 32ft (10m) 9Hz
Image Update Speed Frequency
Thermal Image Palettes Iron, Rainbow, Ice, Greyscale
Thermal Image Minimum Focus Distance . 4"(10cm)
, - ..
Pin Moisture 7% to 30% I ±1.5% MC
Pin Moisture Groups
I30% to 100% Reference only
9 Material Groups
Pin less Moisture Range Oto 100 I Relative
Pinless Measurement Depth
0.75" (19mm) Max
Measurement Resolution 0.1
Response Time Pin less Mode 100ms
Response Time Pin Mode 750ms
Environmental Measurement Range Basic Accuracy
Relative Humidity oto 100% 2.5%R H
Air Temperature 32 to 122 °F (0 to 50°C) ±1.1°F (±06°C)
Dew Point -22 to 122°F (-30 to 50°C) ±1.8° F (±1 0°C)
Vapor Pressure 0.0 to 12.0kPa ±0.05kPa
Mixing Ratio ±2GPP (0.25 g/kg)
oto 560GPP (00 to 80.0 g/kg)
General information
Display Type QVGA (320 x 240 pixeIl2.3" color TFT graphical display
Saved Image File Format BM P with measurement values overlaid
Stored Image Capacity 9999 images
Laser Orientation Single laser pointer to center of thermal image
Continuous Run Time 18 hours max
Typical Usage* 4 work weeks
Battery 3.7V, 3000mAh Li-ion rechargeable via micro USB
Certification Standards EN 61326 (EM C), EN 60825-1 Class 2 (Laser)
Agency Approvals CE, FCC Class B
Includes MR01 Replaceable Temperature and Relative Humidity Sensor, Charging
MR02 Standard Pin Probe, Quick Start Guide, L-_ _ _ _ & Probe
International USB Charger, USB Cable
Connector
OSee FAQs at flir.com/MR176
Register within 60 days
of purchase at
www.ffir.comltestwarranty
Ordering Information UPC EAN
MR176 79395037 1763 0793950371763
M R05 Impact Pin Probe 793950370056 0793950370056
M R06 Wall Cavity Probe 793950370063 0793950370063
MR07 Hammer Probe 793950370070 0793950370070
M R08 Hammer and Wall Cavity Probe Combo 793950370087 0793950370087
M R10 Protective Case 793950370117 0793950370117
www.tech-equipments.comlsales@tech-equipments.com 823
