EXTECH
===INSTRUMENTS
High Current Clamp Meters
Power Clamp e
Powerhouse
MA1500 CAT IV 1500A
The PQ2071 's broad capabilities AC/DC True RMS Clamp
as a power clamp meter Meter + NCV
enable modern industrial and
commercial facilities to trace Integrated Non-Contact Voltage
many electrical and power- Detector to quickly check for the
quality problems. The PQ2071 presence of live wires before testing
can also datalog 50,000 readings
on a USB-connected PC • True RMS for accurate readings
running the included software, of non-sinusoidal waveforms
which enables technicians
to analyze various power • Includes Multimeter functions
issues and realize
actionable insights. • Inrush function captures transients
during motor startups
ACCESSORIES
• Relative Mode for Capacitance
480172 AC Line Splitter Zero and Offset Adjustment
• Data Hold, Peak Hold, MINI
MAX, and Auto Power Off
• Complete with test leads, general
purpose Type K bead wire temperature
probe, 9V battery and carrying case
SPECIFICATIONS MA1500
True RMS Yes
Display counts
Jaw size/Cable size 40,000/4000 count dual LCD w ith bargraph (backlit)
AC Current
DC Current 2.0 " (52mm); 500MCM
Max resolution 1500A
Basic ACA Accuracy (% rdg) 1500A
AC Voltage (Max Res.) 0.01A
DC Vo ltage (Max Res.) ±2.8%
Resistance (Max Res.) 750V (0.01 mV)
Capacitance (Max Res .) 1OOOV (0.01mV)
Frequency (Max Res.) 40MO (0.010)
Temperature 40mF (0.01nF)
Diode/Continuity 40MHz (0.001Hz)
Data Hold -148 to 1832°F (-100 to 1000°C)
M in i M a x / P e ak Yes
Category Rating Yes
UUCE Yes
Dimensions! Weight CAT IV-600V
Warranty CE
11.57x4. 13x1.85 " (294x105x47mm)/ 18 .90z (536g)
1 year
www.tech-equipments.comlsales@tech-equipments.com 99
