===INSTRUMENTS

Non-Contact Current Detector

V£ Locates current in hidden wires and cables up to 1000A
With audible and visible detection

Features:

• Non-contact AC Current range is from 200mA to 1000A

• Locates current flow even where voltage
detectors cannot work

• Detects through shielded wires, conduit
and metal circuit breaker or junction boxes

• Sensitivity adjustment for locating
wires/ conduit through walls

• Ideal for locating hidden conductors

• Dimensions: 5.7 x 1.1 x 1" (145 x 28 x 25mm)
Weight: 1.6oz (45g)

• Complete with smal size pocket clip
and four LR44 button batteries

Applications: Voltage check in an breaker

• Locates wires in conduit Ordering Information:
• Identify underground cables
• Trace low voltage HVAC wiring DA30 ...........Non-Contact Current Detector
• Detect leakage currents
• Find hidden wiring
• Verify energized AC solenoid and motors

Non-Contact AC Voltage and

Current Detector

V£ Detects and pinpoints wide range Voltage and Current
With Sensitivity Adjustment

Features:

• The only two-in-one current/voltage detector Ordering Information:
designed for electrical testing
DVA30 ..........Non-Contact AC Voltage and Current Detector
• Non-Contact AC current detection from 200mA to 1000A
• Non-Contact AC voltage detection from 12V to 600VAC

• Sensitivity adjustments to increase or
reduce sensor trigger threshold

• Loud audible and bright visible sense detect indicators

• Current sensor detects current flow through shielded wires ,
conduit and metal circuit breaker/junction boxes

• Current function detects current flow of 400mA at 0.2" distance
and at much greater distances for larger current flows

• Convenient pocket size with clip
• DimsIWt: 7.6 x 1.2 x 0.9" (192 x 31 x 24mm) / 2.1oz (60g)

• Complete with four LR44 button batteries and pocket clip
