P. 199
FL.UKE ®
1740 Series Three-Phase Power
Quality Loggers Memobox
Compact, rugged and reliable, the Fluke • Plug and play: Set up in minutes with
1740 Series three-phase power quality automatic current probe detection and
loggers are everyday instruments for powering
technicians who troubleshoot and
analyze power distribution systems. • Installs inside the cabinet: Compact,
Capable of simultaneously logging up fully-insulated housing and accessories
to 500 parameters for up to 85 days and fit easily in tight spaces next to live
capturing events, the Fluke 1740 Series power
helps uncover intermittent and hard-to-
find power quality issues. There are three • Monitors power for the long-term:
models to choose from to meet your Data can be downloaded during
basic or advanced power logging needs. recording without interruption
Fluke 1743: IP65 waterproof monitor • Measure voltage with premium
for logging the most common power accuracy: IEC61000-4-30 Class-A
parameters including V, A, W, VA, VAR, PF, compliant voltage accuracy (0.1%)
energy, flicker, voltage events and THO.
• Quickly validate quality of power:
Assess power quality according to
EN50160 power quality standard with
statistical overview
Fluke 1744: Includes the same features
as the Fluke 1743. In addition to common
power parameters, the Fluke 1744 also
measures voltage and current harmonics,
interharmonics, mains signaling,
unbalance, and frequency.
Fluke 1745: Advanced IPSO power quality
logger with the same measurement
capability as the 1744, plus real-time LCD,
five h our UPS.
The included PQ Log software helps you Specifications
to quickly identify the root cause of a
disturbance. (Check the Fluke w eb for detailed specifications)
Included Accessories L •1745 - 1- •1744 - 1- 1743
Fluke 1743/1744/1745: FS17XX IP65-TF-IJ M.easurement of common power parameters: V, A,W, • •
thin flexible current clamp set (1743 & 1744), VA, VAR, PF,energy,flicker, voltage events (dips, swells,
FS17X5-TF-II thin flexible current clamp set intcrruetions) and THO IP 50 •
(1745), VL1735/1745 voltage lead set (1745 Measurement of voltage and current harmonics to the LED + LCD
only), Power Log software, RS232 interface 50th unbalance freQuency and mains siRnalinR IP 65 wat~rproof
cable and RS232-USB adapter, 4 black dolphin Dust/water resistance 8 MB LED LED
clips, WC17XX color localization set, carrying > 5 hrs 8MB 8MB
bag, test certificate with measurement values, Display 3s 3s
•
printed English manual and multi-language Memory ••
manual on CD.
Basic models: Excl. current clamps FS17XX-TF UPS ride·through
EN 50160
Ordering Information Power supply: 88 V ... 660 VAC Size: Fluke 1745: 282 mm x 216 mm x 74 mm;
Fluke 1743/44: 170 mm x 125 mm x 55 mm
Fluke 1743 Basic Power Quality Logger Safety: IEC/EN 61010·1600 VCAT III. 300 V
CAT IV, pollution degree 2. double insulation Weight: Fluke 1745- approx. 3 kg;
Fluke 1743/44: approx. 2lcg
Housing: Fully insulated housing and accessories
Two Year Warranty
Operating temperature: 0 'c to 35' C
Memobox
Interface: RS 232, 9600 ... 115000 Baud. automatic
Fluke 1743 Power Quality Logger Baud rate selection, 3-wire communication
Memobox
Fluke 1744 Basic Power Quality Logger
Memobox
Fluke 1744 Power Quality Logger
Memobox
Fluke 1745 Power Quality Logger
Memobox
FS17x5-TF 4-phase thin flexi current
clamp set, 3000 A
3000/6000A-TF-4 4-phase thin flexi current
clamp set, 6000 A
www.tech-equipments.com I sales@tech-equipments.com 193
