PQ34501PQ3470 3-Phase Power Quality Analyzer/Dataloggers
~ Choice of Numerical or Graphical display with Harmonics model
KIts Available • Large, dot-matrix, sun readable, numerical, backlit LCD
• Optional 200A, 1200A Current Clamps or 3000A Flexible Current Probes
• Captured measurements can be imported directly into Excel via the SD memory card
• Adjustable Current Transformer CT (1 to 600) and Potential Transformer
PT (1 to 1000) ratio for high power distribution systems
• Log up to 30,000 reading on a removable SD memory card in Microsoft Excel'" format
• Wide sampling rate range (2 seconds to 2 hours)
• Built-in Clock and Calendar and easy-to-use on-screen menu
• Banana style input jacks and easy-to-hold rugged over molded housing
• Complete with meter, 4 voltage leads with alligator clips, 8 AA batteries,
SD memory card, Universal AC adaptor (100 to 240V), and durable hard
carrying case. Clamp probes sold separately; 1 year warranty
Model PQ3470 Additional Features
• On-screen Harmonics display (1 to 50th order)
• Simultaneous display of Harmonics and Waveform
• Simultaneous display of Voltage and Current waveforms
• Display of Waveform with peak values
• Analysis of Total Harmonic Distortion (THD)
• Graphic Phase diagram with 3-Phase system parameters
• 3-phase Voltage or Current Unbalanced Ratio (VUR, AUR) and unbalanced factor
• Capture Transient events Oncluding dip, swell, outage) with programmable threshold (%)
SPECIACATIONS RANGE BASIC ACCURACY
CE AC Voltage (True RMS) 600.0V ±(0.5%rdg)
ACCurrent 1200A ±(0.5% rdg)
Patent Pending Active Power (MW) 9.999MW ±(1.0%rdg)
Apparent Power (MVA) 9.999MVA ±(1.0%rdg)
Clamp Probes for PQ3450 & PQ3470 Reactive Power (MVAR) 9.999MVAR ±(1.0%rdg)
Power Factor 0.00 to 1.00 ±0.04
Choose from clamp probes ranging from 200A to 3000A Frequency Range 45Hz to 65Hz ±O. l H z
Phase -180· to + 180.0· ±1·
and flexible vs traditional jaw. Harmonics (PQ3470) 1 to 50th ±2% (1 to 20); ±4% (21 to 31)
Crest Factor (P03470) 1.00 to 99.99 ±(5%)
Current Clamp input 200mV, 300mV, SOOmV; ±(0.5%rdg)
1V, 2V, 3V; user-adjustable
Active Power Energy (MWH) O.OkWh to 9.999MWH ±(2.0%rdg)
Apparent Power Energy (MVAH) O.OKVAh to 9.999MVAH ±(2.0%rdg)
Reactive Power Energy (MVARH) O.OkVARh to 9.999MVARH ±(2.0%rdg)
Datalogg ing 30,000 data (2GB SD Card)
Peak AC Voltage/Current Accuracy ±(5%) P03470 only
CEICAT rating
Dimensions! Weight CEICAT 111-600V
8.86 x 4.92 x 2 .52 " (225 x 125 x 64mm)/ 2.21bs (1010g)
PQ34-2: 200A Current PQ34-12: 1200A Current OROERING 3-Phase Power Analyzer/Oatalogger
C lamp Probes w ith 0 .8 " Clamp Probes with 2" 3-Phase Graphical Power and Harmonics AnalyzerlDatalogger
(19mm) jaw opening (50mm) jaw opening P03450
P03470 200A Power Analyzer Kit: P03450 with P034-2
PQ34-30: 3000A Flexible Current PQ3450 Kits 1200A Power Analyzer Kit: P03450 with P034-12
Clamp Probes (24"/600mm) for P03450-2 3000A Power Analyzer Kit: P03450 with P034-30
wrapping around busbars. P03450-12
P03450-30 200A Power Analyzer Kit: P03470 with P034-2
PQ3470 Kits 1200A Power Analyzer Kit: P03470 with P034-12
P03470-2 3000A Power Analyzer Kit: P03470 with P034-30
P03470-12
P0347-30 Voltage Test Leads with Alligator and Plunger Clips (4 leads)
Accessories 200A Current Clamp Probes (Set of 3)
POI 000 1200A Current Clamp Probes (Set of 3)
P034-2 3000A, Flexible Current Probes (Set of 3)
P034-12
P034-30
