Scopemeter Portable
Oscilloscopes 190 Series II
The toughest portable scopes ever built
The 190 Se-ries II in a nutshell: Rated all the way to CAT IV
o The 190 Series Ii covers the bandwidth ScopeMeter test tools are rugged solutions
built for industrial troubleshooting. The
of 60MHz to 500MHz with ScopeMeter Fluke 190 Series II are double-insulated
models floating oscilloscopes safety rated for
o 190-XX4 models with four independent measurements up to CAT III 1000 V /CAT N
isolated inputs and DMM readout 600 V environments.
o 190-XX2 models with two independent
Measure from mV to kV safely
isolated scope inputs and a DMM input
o Up to four lIser selectable channels Independently isolated inputs allow you
o Up to 33 user selectable readin~s to make measurements in mixed circuits
o Fast sample rate: up to 5Gs/s Wlth up to having different ground references
reducing the risk of accidental short
200ps resolution circuits. Conventional bench oscilloscopes
o Single shot, pulse width and video without special differential probes and
isolation transformers can only reference
triggering measurements to line power earth ground.
o Deep memory: 10000 points per trace The 190 Series Ii are ready for the most
challenging tasks. With standard probes
waveform capture that cover a wide application range from
o CAT III 100()lV / CAT N 600V safety rated mV to kV, you are ready for anything from
o IP 51 rated: Dust- and drip water proof micro-electronics to heavy-duty higher
o Isolated USiBports for memory devices voltage electrical applications.
and PC connectivity JP-S1 rated for harsh environments
o Up to seven hours of operation with high
Rugged and shock-proof, ScopeMeter
performance Li-Ion batteries portable oscilloscopes are built for dirty,
o Easy access to the battery compartment hazardous environments.With its sealed
o Security slot to lock down instrument case, it can endure dust, drips, humidity and
airborne pollutants. Every time you reach
using standard Kensington~ lock. for your ScopeMeter you can be confident it
o Connect-and-View™ triggering for will work reliably wherever your work takes
you.
intelligent, automatic triggering on fast,
slow and even complex signals
o Conversion to a frequency domain using
FIT analysis
o Automatic Capture and Replay of 100
screens
o ScopeRecord™ mode gives 30000 points
per input channel for low frequency signal
analysis.
o Trendplot™ paperless recorder mode with
deep memory for long-term logging of
automatic measurements
The toughest portable scopes
ever built
Fluke introduces the 500MHz version
equipped with 4 isolated channels.This new
ScopeMete~ test tool, the 190-504, brings its
wide bandwidth in the palm of your hand
with a maximum flexibility of measuring
channels. Conveniently verify the systems
performance right "on the spot", fully safely
without carrying bulky lab equipment
around.
What could you do with four
channels?
What could you do with four channels?
The 190-504 opens up a new generation
of applications where a four channel
ScopeMeter can proof its functionality. You
can hook on voltage probes and current
clamps in combination with a temperature
probe to get the best information out of
your signals without sacrificing a probe
input. In a Motor and Drive environment
you need at least three inputs to get a good
insight in the quality of the signal coming
from the VFD. You can switch over to a DMM
reading without swapping probes.
