UKE ®
ScopeMeter Portable
Oscilloscopes 120 Series
Three-in-one simplicity
The compact ScopeMeter 120 Series
is the rugged solution for industrial
troubleshooting and installation
applications. It's a truly integrated test
tool, with oscilloscope, multimeter and
"paperless" recorder in one affordable,
easy-to-use instrument. Find answers to
problems in machinery, instrumentation,
control and power systems quickly and
easily.
• Dual-input 40 MHz or 20 MHz digital
oscilloscope
• 1\vo 5,000 counts true-RMS digital
multimeters
• A dual-input TrendPlotlM recorder
• Bus Health Test for industrial bus
systems (Fluke 125)
• Connect-and-View™ trigger simplicity
for hands-off operation
• Power Measurements and Harmonics
Measurement (Fluke 125)
• Shielded test leads for oscilloscope,
resistance and continuity
measurements
• Up to 7 hours battery operation
• 600 V CAT III safety certified
• Optically isolated interface for
PC connection (optional)
• Rugged, compact case
Connect-and-View™ triggering for
an instant, stable display
Scope users know how difficult triggering
can be. Wrong settings show unstable
and sometimes wrong results. Fluke's
unique Connect-and-View recognizes
signal patterns, and automatically sets
up correct triggering. It provides a stable,
reliable and repeatable display of virtually
any signal - including motordrive and
control signals - without touching a
button. Signal changes are instantly
recognized and settings adjusted for -
once again - a stable display.
Optional accessories Fluke 120 series
Voltage Probe Set
220
Use 1'rendPlot™ to help find
interrnittents fast
The toughest faults to find are those
that happen only once in a while:
intermittents. They can be caused by
bad connections, dust, dirt, corrosion
or simply broken wiring or connectors.
You may not be around to see it - your
Fluke ScopeMeter will. In this "paperless
recorder" mode, you can plot the
minimum and maximum peak values
and average over time - up to 16 days.
Bus Health mode (Fluke 125)
Bus Health mode gives a clear "Good!
Bad" indication for the electrical signals
on industrial buses and networks, such
as CAN-bus, Profi-bus, RS-232 and many
more. The Fluke 125 validates the quality
of the electrical signals as soon as any
electrical signals are passed along the
network.
i1I227.3u,:
,~O.O.3.t!l!'! .. :.... :lIuro... :.... :.... :.... :..
~:. A':M:;r''1"':-:11:'
... : ... :. ..:. ":' 1
Ii . . , . .
.:: .:
: U :r
::: :: ::: ::
Connect-and-Vlew captures (i!. True RMS
even the most complex motor
drive signals. c us
Included Accessories
PM 8907 line adapter/charger, STL120-III
shielded test leads set (1 red, 1 grey) including
hook clips, BB120 shielded BNC adapter,
BP120MH NiMH battery pack, VPS4O- III wide
bandwidth Voltage Probe (Fluke 124/125),
TL175 Safe-guard testlead, i400s current
clamp (Fluke 125), Getting Started booklet,
user's manual (cd-rom)
Ordering Information
Fluke 123 Industrial ScopeMeter<" (20MHz)
Fluke 123/S Industrial ScopeMeter<" (20MHz)
+ SCC120 kit
Fluke 124 Industrial ScopeMeter<" (4OMHz)
Fluke 124/S Industrial ScopeMeter0 (4OMHz)
+ SCC120 kit
Fluke 125 Industrial ScopeMeter (40 MHz)
Fluke 125/S Industrial ScopeMeter (40 MHz)
+ SCC120 kit
