M eggerm

FRAX Series

Sweep Frequency Response Analyzers

• Highest dynamic range and accuracy in the industry
• Smallest and most rugged FRA instrument in the industry
• Fulfills all international standards for SFRA measurements
• Advanced analysis and decision support built into the

software
• Imports data from other FRA test sets

Ordering information Art. No.

Item AC-1 9090
FRAX-101 AC-1909 1
With accessories, 18 m (60 ft) cable set AC-1 9092
AC-19093
With accessories incl. battery, 18 m cable set
AC-29090
With accessories, 9 m (30 ft) cable set AC-29092
AC-29095
With accessories incl. batter}', 9 m cab le set AC-29096
FRAX-99
With accessories, 9 m cable set AC-39090
With accessories, 18 m cable set AC-39092
With accessories, incl. batte r~, 9 m cable set
With accessories, incl. battery, 18 m cable set

FRAX-150
With accessor 18 m cable set
With accessor 9 m cable set

ORDERING INFORMATION Resonating Inductor

Item (Qty) Cat. No. and Adapter Kits
Resonating Inductor f or use w ith
DELTA2000IDELTA3000 670600 • Expands the range of capacitance and dissipation
670600-1 factor (power factor) test sets
Resonating Inductor f or use w it h DELTA4000
• Capable of tuning capacitances up to 1IJF at 10 kV
• Hand-crank tuning wheel
• Core gap gauge that displays position of inductor core
• Large wheels and handles for easy transport

IDAX 300/350

Insulation Diagnostic Analyzers

• Automated measurement and analysis of moisture content, tan
delta/power factor and oil conductivity

• Individual temperature correction (ITC) of tan delta/power factor
and oil conductivity

• 40% faster measurements with the new IDAX 5.0 SW
• Reliable measurements in high-interference environments
• Multi-function test set for transformer measurements

Ordering information Art. No.
AG -19090
It em AG-19092
IDAX300
IDAX300S AG-19 192

IDAX350
With internal computer

www.tech-equipments.comlsales@tech-equipments.com 397
