Overhead line systems

Short-circuiting Easier installation Self locking contact clamp:
and earthing features. powerful conductor clamping
systems and very good performance at
short-circuiting, does not slide.
Installed from the ground on conductors upto 10.50 m.

Reference Rating conductor More rigid metallic stick.
MT-508/36 (kA/1 5) Lower tube 30.6 mm dia.
o Upper tube 16 mm dia.
8 MT-512136
mm
3-22

MT-508/46- - - - - -8- - - - - - - -3--22- - - - - Re-inforced insulating
stick (36 mm dia.).

Reference Composition MT-650
MT-508/36
MT-508/46 3 telescopic metallic sticks 3 elements CM-4-165-B On all models: Reinforced
L = 6.00/2.37 m- 2.4 kg - MT-512136 insulatingpole: Epoxy/fibreglass
resin over 0 36 mm PV foam
1 insulating stick with a non-skid area.
2 elements 1.65 m - MT-531 This equipment can be used
for rigid deployed poles
Reel for 3 cables 10m x35 mm2 with for easy installation.

earth connect. for attachment to stick - MT-543/35

1 earth rod 1 m - MT-650

1 bag. 2.50 x0.30 x0.15 - 10.5 kg - M-87-127
3 telescopic metallic sticks 4 elements
L = 5.10/1 .62 m - 2.1 kg - MT-512146

1 insulating stick
2 elements 1.65 m - MT-531

1 insulating intermediate
stick element 1.65 m - CM-4-165-B

1 stick lifter - MT-546

Reel for 3 cables 10m x 35 mm2 with
earth connect. for attachment to stick - MT-543/35

1 earth rod 1 m - MT-650
1 bag M-87-208

Self-locking clamp
No springfor easier
maintenance, removal,
and greater reliability.

On-the-spot voltage testing

with aCC-765 detector
attached to a metal pole
with acombination
Ve/flag antenna.

Medium Voltage Equipment I Overhead line systems 551

- Total length Mil Weight (2) Diameter
mm
