lEG equipment

lEG short-circuiting Operation eyelet. IEC 61230
and earthing systems
(three-phase crossarm networks) ~

MT-613 clamps are automatic contact clamps.They are put into position from
above the conductor, using the clamp dispenser head MT-635l1-C.

) Fitting up. I

Reference Equipment composition Speed clamping.
MT-6613
3 automatic contact clamps MT-613
MT-6613/1 Connection cables 35 mm2, max.
gap between clamps: 2.75 m
Clamp Double
1 clamp dispenser head MT-63S/1-C dispenser crimping
1 spool with earthing cable connection MT-640-S head lugs.

1 carrying bag M-87295 Extra flexible
3 automatic contact clamps MT-613 cable with
silicone
Connection cables 95 mm2, max. sheathing.
gap between clamps: 3 m

1 clamp dispenser head MT-635/1-C
1 earthing cable connection 15 m x 35 mm2

1 earthing clamp MT-840/1
1 carrying bag M-87295

Characteristics Rating Connection copper Earth connection conductor
(kAI1 s) cable between copper cable (mm2)
Reference clamps (mm2) 0
MT-6613 * 8 35 mm2 16mm2
MT-6613/1 ** 17.5 35mm2 mm
95 mm2 5 to 30

5to 30

* Recommended sticks: CE-4-21-C.
** Recommended sticks: CM-4. CF-5. CM-7 et CM-4000.

• Remarkable rapidity and ease of handling.
• Removal is carried out by pulling down

the clamp, which revolves around the conductor
by means of the pig tail fixed in the centre
of the clamp dispenser head.

___ Total length J!l. Weight o Diameter

mm
