Copper and aluminium cables

Equipotential Lines IEC-61230

USE ~

Conductive line connecting two pieces of metallic pieces in order to give
them the same potential.

- cable composition and features:
35 mm2 copper cable insulated in agreen silicone sheathing.
Double crimped lugs at the cable ends.

Reference Characteristics
M-24-35-V Gable 35 mm

- Cla~ and stick composition and feabJres:
Insulating stick equiped with aclamp MT-735 in aluminium alloy with

o15 to 60 mm clamp capacity.

Reference Characteristics
MT-735-P4 Clamps MT-735 on stick 400 mm

- Earth Clamp composition and feabJres:

All the earth clamps are available to complete

the equipotential lines.

Aluminium cables

Extra flexible braided multi-strand cables.
Transparent PVC sheath,with cable section identification.

Reference Rating Cable Section
(mm2)
M-28-70 o(kAtl s) Weight (kg/m) (mm)
M-28-120 70
M-28-150 10.0 0.240 13.4 120
150
17.5 0.430 19.00

20.0 0.510 21 .00

Short-circuiting and earthing
system carrying bags

Can receive earthing system equipment (clamps and cables).

Reference 0 &

M-87-53 mm 2
M-87-153 380 x 250 x 400 2.5
M-87-295 380 x 250 x 600 1.5
550 x 300 x 300
