Portable Filters Carts (EPF / EFP)

• Packaged, compact units for liquid filtration. SYSTEM PERFORMANCE:
• Completely self-contained and wired ready
FLO W - 6 US Gallons per minute
for field service. FLUID - Hydraulic or lube oil, 600
• Easy handling and portable. SSU max.
• Accommodates a large range of specific PUMP DISCHARGE PRESSURE -
50 psig
applications. MOTOR - 1 /3 HP, 1200 rpm
capacitor start
DIMENSIONS: HOSES - one suction and one
discharge (optional)
Height: 40.5" (1029 mm) DOLLY - Two wheel with double
Width: 25.5" (648 mm) handles. Wheels 8" dia. Polyolefin
Depth : 22" (559 mm) 600 Ibs. capacity
Weight: 1251bs (57 kg) FILTRATION - Standard unit
equipped with Enervac model EP-
STANDARD VOLTAGE: 718-10 filter element (10 micron) or
as specified
120VAC-1PH-60Hz, 10 amp INLET STRAINER - Y Type 25 mesh
POWER CONNECTION - 15 ft.
3-conductor rubber insulated power
cable

Industrial Filter (E858A)

• Wide media selectivity - interchangeable cartridges.
• High dirt-loading capacity.
• Assures maximum, continuous clarity.
• ASME code designed and labelled.

Air & Gas Filters • 99.7% filtration efficiency. Strips fine mists which pass
through other filters.
• Efficiency unaffected by conditions.
• Low initial pressure drop.
• Clogging and fouling eliminated.

Replacement Elements

• One of the most complete lines of filtration replacement media
available.

• Elements are made from the highest quality materials.
• Removal by absorption, adsorption, coalescing, separating and

mechanical filtration.
• Elements are carefully manufactured, inspected and backed by

a full warranty.
