IR

Specifications

Technical Summary MAX Range Basic Accuracy

Insulation Resistance 4M to20Gn ±1 .5%
Insulation Test Voltages 50, 100, 250, 500 and 1000V ±3.0%
DC Voltage ± 0 .1%
AC Voltage 1000.0V ±1.5%
VFD AC Voltage 1000.0V ±1.5%
Earth Bond Resistance 1000.0V ±1 .5%
Capacitance 40nto 40Kn ±1 .2%
Frequency (ACV) +/- 5 digits
Diode Test 10mF ±1 .5%
Continuity 40kHz ±0.5%

General Information 2V
400.0n
IP Rating, Drop Test
Category Rating IP 54, 3m (98')
Bluetooth Range CAT 111 -l000V, CAT IV-600V
Battery Type
Memory 10m (32')
Warranty 6xAAA
99 internal storage locations
Limited Lifetime*

* When registered within 60 days of purchase.

Ordering Information

IM75.. .............. Insu lation & DMM with VFD and M ETE RLiNKTM
IM75 -NIST ..... ... IM75 w it h Certificate of Traceabil ity to NIST

Accessories

TA1O .. ..... Protective case for DM9x and IM7x Series
TA50 ..... Magnetic Hanging Strap
TA70 ... ..CAT IV Insu lated Alligator Cli ps
TA80 ..... CAT IV Si licone Test Leads
