TERTEST
PARAMETERS OF OPTIONS C 200 AND C 200B
Pal ameter Ran ge Settings range Reso luti on Acc ul acy Maximum Load
57V 0,50...60,00V O,OlV 250mA@60V
Voltage 1l0V 1,00... 130,00V O,OlV ±0,05 % of set 136mA@130V
220V 2,0 ... 250,OV O,lV value ±3 digits 68mA@250V
380V 3,0.. .420,OV O,lV 39mA@420V
lA 0,0100.. .1,3000A 0,0001 A 12V@1,3A
SA 0,050...6,000A O,OOlA ±0,05 % of set 3V@6A
O,OOlA value ±3 digits
IV@20A
Current 20A 0,200... 19,999A 2V@20A**)
100A**) 1,00... 100,00A O,OlA ±O,l % of set 0,7V@50A
value ±3 digits 0,3V@100A
Frequency 45,00...52,50Hz O,OlHz ±0,02Hz
Phase shift 0 ,0 ... ±90,0 ° 0,1 ° ±0,5° *)
THD of voltage and current 0,5% of set value
Weight and dimensions (with x height x depth) 14kg and (478x194x342)mm
Power supply 230V±10% /45 ... 65Hz / 130VA (200VA for C200B)
*) for settings greater then 10% of voltage and current range
**) C200B option with additi ona l IOOA range
Calpro C300 Software for C300 Calibrators ZW10/20A Coil
PC Software for control of 10 turns coil for current up to
calibrator C300 and automatic 20A for clamps and clamps meters
testing of power industry checking to 200A and having small
equipment. diameter from 9mm, by using with
calibrators series C1 01, C200, C233
i C300
ZW1 00/1 OA Coil U101 Handle for Calibrators
100 Turns Coil for current up to Handle for carrying C1 01, C200
10A for clamps and clamps meters and C300 series calibrators and
checking by using with calibrators setting them in adequate angle
series C1 01, C200, C233 i C300 with relation to horizontal level.
928 www.tech-equipments.comlsales@tech-equipments.com
