Specifications of calibrator's inputs for automatic tests

SO impulse input for counting impulses input voltage and cm-rent range SO (DIN43864) or 0 ... 2V/4 ... 30V
from electricity meter or photo scanning impulses frequency up to 100Hz
0... 999,999s
head (SO impulse input) impulses counting time 0... 99999

number of counted impulses O... 10,000V or 0 ... 100,00mA or
0... 5,000A
DC measurement input input voltage and current range
(Idc ammeter input and Udc voltmeter error of measurement 0,1% of range
number of inputs 3
input) time measurement
range 0,001.. .100,000s
Start/stop input for time measurement error 0,001 s
(Timer input t)
l5 ... 250V DCIAC
Binary outputs operate/standby for input voltage range 2
calibrator state signaling number of inputs
O,OOls
setting time 100Vac / 130Vdc / lOOmA
output load

General parameters 34kg and (478xI94x490)mm
Weight and dimensions (width x height x depth) 230V± 10% I 45 ...65Hz 1700VA

Power supply

caDD Power Calibrator and Tester with notebook

ISO 9001 :2008

o Voltage source up to 500 V
o 3- phase current source up to 120A and

1- phase up to 360A

o Voltage and current harmonics
programming up to 31

o Power quality parameters simulation

o Impulse input for electricity meters testing
o Start! stop inputs for protective relay testing
o AC measurement input for transformers

and clamps testing

o DC measurement input for transducer
testing

o RS 232C interface and Bluetooth interface
for PC software Calpro 300
