===INSTRUMENTS

Milliamp Clamp Meters

380950 80A 380941 200A 380947 400A
AC/DC Mini Clamp ACmC Mini Clamp AC/DC True RMS Mini
Meter Meter Clamp Meter

Small jaw size (O.5"/12mm) High resolution mini clamp with True RMS mini-clamp with high 1mA
fits into tight spaces Voltage, Frequency, and Resistance AC current resolution

• 1mA resolution • High resolution to 1OmA AC/DC • Non-contact Frequency measurements
• Voltage, Resistance, Frequency • Fast 40 segment bargraph to 10kHz through the clamp jaws

and Duty Cycle measurement • One touch Auto Zero for • Fast 40 segment bargraph
DC Current measurements
• Auto power off • One touch Auto Zero
• CAT 11I-600V • Complete with test leads, wrist strap, • Complete with wrist strap,
• Complete with test leads, 2 AA batteries and carrying case
2 AA batteries and carrying case
carrying case and two
1.5V AAA batteries

380950 380941 380947

4000 count LCD 4000 count LCD True RMS
0.5 " (12mm); 3/0 AWG 0.9" (23mm); 4/0 AWG 4000 count LCD
4.000A, BO.OA 40A, 200A 0.9 " (23mm); 4/0 AWG
4A, BOA 40A, 200A 4A, 40A
1mA 0 .01A A C / D C 40A, 400A
±2.5% ±1.0% AC: 0.001A, DC: 0.01A
600V (0.1mV) 400V (0.1 V} AC: ±1 .5%, DC: ±1.0%
600V (0.1mV) 400V (0.1 V}
40MQ(0.Hl} 400Q(0.1Q} 10kHz (0.01 Hz)
1OMHz (0.001 Hz) 100kHz (0.001 Hz)
Continuity Continu it y Yes
Yes Yes MiniMax
Max MiniMax UL, CE, CAT 11I -300V
CE, CAT 11 1-600V UL, CE, CAT 11 1-300V 7x1.Bx1.3" (17Bx45x32mm)
B.2x2 .7x1.4 · (210x70x37mm) 7x1 .75x1.25 " (17Bx45x32mm) Boz (225g)
70z (200g) Boz(225g} 1 year
1 year 1 year
