===INSTRUMENTS

EX300 Series Mini Digital MultiMeters + Voltage Detector

Combination MultiMeter with non-contact AC Voltage Detector

• Built-in non-contact AC Voltage Detector with red LED indicator and audible beeper
• Large 1" digits makes display easy to read
• Dimensions: S.7x2.9x1.6" (147x76x42mm); Weight: 90z (260g)
• 1 year warranty
• Complete with stand , test leads, protective holster, batteries, general

purpose Type K bead wire temperature probe (EX330 only)
Model EX310 (Manual Ranging)
• Battery test 1.SV and 9V
Model EX320 (Autoranging)
• Max Hold, Data Hold, and Auto Power Off
Model EX330 (Autoranging)
• Data Hold and Auto Power Off
• Advanced functions include Type K Temperature, Capacitance, and Frequency

SPECIFICATIONS EX310 EX320 EX330 c@us CE
2000 counts 2000 counts 4000 counts lISTEO
Display Counts 0.50% 0.50% 0.50 %
Basic Accuracy 100 to 600VAC 100 to 600VAC 100 to 600VAC , . DETECTOR
NCV Detector 0.1mV to 600V 0.1mV to 600V 0.1mV t0600V
DC Voltage O.1V t o 600V 0.1mV to 600V 0.1mV t0600V Integrated Non-contact
AC Voltage 0.1mA t0 10A Voltage Detector for
DC/ AC Current 0.10 to 2000kn 0.10 to 20MO 0.10t0 40MO quickly checking the
Resistance 0.001nF to presence of live wires
Capacitance Yes Yes 0.001Hz to 10MHz before testing.
Freq uency CAT 1I 1·600V, CAT 1I-1000V CAT 111-600V, CAT 1I- 1000V ·4 to 1382' F (-20 to 750' C)
Temperature 0.1 to 99.9%
Duty Cycle Yes
Diode/Continuity CAT 11I-600V, CAT 1I-1OOOV
Category Rating

ORDERING Manual Ranging 9 Function Mini MultiMeter + Non·Contact Voltage Detector
Aut oranging 8 Function Mini MultiMeter + Non-Contact Voltage Detector
EX310 Aut oranging 12 Function Mini MultiMeter + Non-Contact Voltage Detector
EX320 Vinyl pouch carrying case
EX330 Replacement Bead wire Temperature Probe (-22 to 572' F/-30 to 3OO' C)
409996 Replacement Test Leads
TP873
TL803

Digitial MultiMeter (DMM)

Pick the right MultiMeter for your application

MN Series EX200Series EX300 Series EX400 Series EX500 Series MP & MM Series GX900 Series MG300 Series
Compact and Mini Digital DMMs
affordable Digital Mini Digital with built-in Professional Full Industrial Series These two series of FlagshipTrue RMS Combines a 1000V
MultiMeters with Size Series Digital Digital DMMs are rugged and reliable
MultiMeters with models featuring Noncontact Voltage accurate and rugged. DMM with graphical Insulation Resistance
choice of Manual low costTrue RMS Detector with models MultiMeters. Features Waterproof, dustproof, DMMs feature
for better accuracy include Large Digits, drop tested to 2m extreme accuracy, backlit display for Tester with aTrue
Ranging or and Infrared to choose between (6.5"1, and CAT IV
Autoranging models. Manual Ranging or Manual Ranging or safety rated for higher resolution, and viewing trend data, RMS CAT-IV Digital
Thermometer. CAT 111- Autoranging, True voltage applications. functionality, perfect
Perfect for DIVers, 600V safety rated. Autoranging and Wireless datalogging Low Pass for MultiMeter plus
students, hobbyists, numerous electrical RMS or Averaging, model or built-in IR for troubleshooting
mechanics and readings and and Type K Thermometer. complex equipment capturing accurate and wireless connectivity
tec hnicians. temperature. temperature in advanced
measurements. manufacturing. stable readings on VFD to a PC for safer

equipment, wireless monitoring, data

datastreaming to PCs recording and

and Android devices diagnostics.

for safer/easier

diagnostics, and a

CAT-IVsafety rating.
