EXTECH
===INSTRUMENTS
EX570 CAT IV Industrial MultiMeter + IR Thennometer
Built-in IR Thermometer quickly identifies hot spots without contact Built-in IR Thermometer
• Built-in non-contact IR Thermometer design with laser pointer quickly locates hot spots on
• True RMS CAT 111-1OOOV, CAT IV-600V rated with 0.06% basic DCV accuracy electrical panels and HVAC
• Diode open circuit voltage of 2.8V DC vents without contact.
• Heavy duty Double molded, water resistant package
• Large backlit 40,000 cou nt LCD with 40-segment
bargraph; Auto off with disable featu re
• Memory for storage and recall of t hree measurements
• 1000V input protection on all functions
• Type K thermocouple contact temperatu re measu rements
• Features Hold, Relative and Peak Hold, Min, Max and Average recording
• Complete with double molded test leads, magnetic hanging strap, general
purpose Type K bead wire probe, case, and 9V battery; 3 year warranty
SPECIFICATIONS ± 0 .0 6%
0.0 1mV to 1000V
Basic Accuracy
DC/AC Voltage 0.01IlA to 20A
DC/AC Current
Resistance O.O Hl to 40MO
CapaCitance 0.OO1nF t o
Frequency 0.0001Hz to 40MHz
Temperature (fype KI non-contact IA) Type K: -SO to 1382' F (-45 to 750' C) I IA: -22 to 1022' F (-30 to 550' C)
Field of View 30:1 ratio
Duty Cycle 0.01 to 99.99%
Diode (2 .8V)/Continuity Yes
Dimensions! Weight 7.25x3.25x2.25" (1 84x83x57mmV 12 .3oz (349g)
ORDERING CAT IV Industrial MultiMeter + IA Thermometer
EX570
EX5401EX542 CAT IV MultiMeterlDataloggers with Real Time Streaming
Transmitter CAT IV True RMS MultiMeter datalogs up to 9,999 readings with wireless
USB interface capability to transmit readings to your PC in real time
• Real time datalogging or wireless data transmission directly to your PC (30fV1 0m)
• True RMS measurements for accurate AC Voltage and Current measurements
• Diode open circuit voltage of 2.8V DC and 1000V input protection on all fun ctions
• Double molded construction for waterproof (I P67) protection
• CAT IV-600V safety rating for industrial applications
• Dual sensitivity frequency functions
• Large backl it tri ple LCD display w ith 40,000 counts; Auto off with disable feature
• Complete w ith double molded test leads, magnet ic hanging strap, general
purpose Type K bead wire temperature probe, remote receiver with USB cable,
Windows" compatible software, 9V battery and carrying case; 3 year warranty
continuous wireless data SPECIFICATIONS ±0.06%
0.0 1mV to l000V
streaming to a PC in real Basic Accuracy
time, drop-proof tested to DC/AC Voltage 0.01 IlA to 20A
DC/AC Current
6.5ft (2m), and waterproof Resistance O.OHl to 40MO
design (IP67). CapaCitance 0.001 nF t o 40mF
Freq u e n c y 40Hz to 4kHz (el ectrical) I 0.00 1Hz to 100MHz (electron ic)
Temperature -58 to 1382' F (-50 t o 750' C)
Duty Cycle 0.1 to 99.90%
Diode (2 .8V) I Continuity Yes
Dimensions! Weight 7.25x3.25x2.25· (1 84x83x57 mmV 12.30z (349g)
ORDERING
EX540 CAT IV M uttiMeterlDatalogger w ith Aeal Time Streaming (915MHz)
EX542 CAT IV M uttiMeterlDatalogger w ith Aeal Time Streaming (433MHz)
(NOTE: USA, Mexico , and Canada use 915MHz model and majority of other countries use 433MHz modeQ
