EXTECH
===INSTRUMENTS
MG300IMG302 CAT IV Insulation Tester
MultiMeter with Wireless PC Interface
......, nnn I" Combines a 1000V Insulation Tester with a True RMS MultiMeter
UUU I • Wireless USB interface transmits measurement data to a PC
........ .... • Backlit large tri ple display and waterproof (IP6?) rugged housing design
• Insulation Resistance from 0.001 MQ to 4000MQ
Lf 'OJ.O • Auto discharge of capacitive voltage
• Lock Power On Fu nction for hands-free operation
• MiniMax, Relative mode, Data Hold, and Auto power off
SPECIFICATIONS RANGE RESOLUTION BASIC ACCURACY
Insulation Resistance 4MQ. 40MQ, 4ooMQ, 4000MQ 0.001MQ ±3%
Insulation Test Voltages
ACIDC Voltage 125V. 250V. 500V. 1000V AC: ± 1%. DC: ±0.06%
AC: ± 1.S%. DC: ±1%
ACIDC Current 1000V 0.1mVAC/ 0.01 mVDC ±0.3%
Resistance ± 3.5%
CapaCitance 10A ±0.1%
Frequency ± 1.2%
Duly Cycle 40MQ 0.010 ± 1% + 4.S' F (2.S'C)
Temperature
4-20mA% 40mF 0.001nF
Continuity/Diode
Dimensions! Weight 100MHZ 0.00 1HZ
Includes remote 0. 1 to 99.9% 0.0 1
receiver with USB cable,
Windows'" compatible -58 to 2192' F (-SO to 1200' G) 0.1' F (0.1'G)
-25 to 125% 0.01%
software, heavy duty
test leads, alligator clip Yes
7.8 x 3.6 x 1.9" (200 x 92 x 50mm)/ 20.50z (582g)
test lead, Type K bead
wire temperature probe, OROERING NOTE: USA, Mexico. and canada use 915MHz model MG300 and majority of other countries use 433MHz model MG302
CAT IV Insulation Tester/MultiMeter with Wireless PC Intefface (91SMHz)
hard case, and 6 x AA MG300 CAT IV Insulation Tester/MultiMeter with Wireless PC Intefface (433MHz)
batteries; 1yr warranty MG302
NEW MG300-ETK Electrical Troubleshooting Kit
Includes three compact tools that are indispensable at a customer site for
electrical installation, troubleshooting, and repair
- • Model MG300 or MG302: 13 Function, Wireless PC Interface,
True RMS Multimeterllnsulation Tester (see above)
• Model 42509: 12:1 Infrared Thermometer with high/low alarm and fast
2-color display for processes that require temperature control and
monitoring; measures from -4 to 950°F/ -20 to 510°C
• Model MA430T: 400A True RMS AC Clamp Meter with built-in non-contact voltage
detector and ideal for noisy or non-sinusoidal AC measurement
• 1.2" (30mm) jaw size for conductors up to 350MCM
• Supplied with test leads, Type Kthermocouple bead wire probe, batteries, and case
OROERING Electrical Troubleshooting Kit (with MG300)
Electrical Troubleshooting Kit (with MG302)
MG300-ETK
MG302-ETK
MG300-MTK Motor & Drive Troubleshooting Kit
Includes three compact tools that are indispensable at a customer site from
troubleshooting 3-phase motors and drives
• Model MG300 or MG302: 13 Function , Wireless PC Interface,
True RMS Multimeter/lnsulation Tester (see above)
• Model 480403: Motor Rotation and 3-Phase Tester checks phase sequence and
indicates rotation direction of t he motor to help insure correct wiring
• Model MA435T: 400A True RMS AC/ DC Clamp Meter with built-in non-contact
voltage detector and ideal for noisy or non-sinusoidal AC measurement
• 1.2" (30mm) jaw size for conductors up to 350MCM
• Supplied with test leads, 3 large color-coded alligator clips, Type
K thermocouple bead wire probe, batteries, and case
OROERING Motor & Drive Troubleshooting Kit (with MG300)
Motor & Drive Troubleshooting Kit (wit h MG302)
MG300-MTK
MG302-MTK
