Ģ Cold Shrink QT-II Terminations
3M™ Cold Shrink QT-II 5620K Series Termination Kit includes three 1-piece, non-skirted single-phase terminations. It
ensures a pliable, tight seal for tape shield, wire shield and UniShield® power cables. The conjunction of high dielectric-
constant material and silicone rubber insulation allows the termination to withstand voltages of 5 to 15kV.
• Provides a void-free seal to tape shield, wire shield and UniShield® power cables
• High dielectric-constant material regulates the distribution of electric field stress
• Suitable for indoor applications
• Termination has 0.78 to 1.30-in insulation 0.0.
• Accommodates wire sizes of 300 to 750 kcmil at 5kV 100%, 250 to 750 kcmil at 5kV 133%/8 kV 100%, 4/0 AWG to
600 kcmil at 8 kV 133%, 2/0 AWG to 500 kcmil at 15kV 100%, 1 AWG to 350 kcmil at 15kV 133%
• Non-tracking, molded, silicone rubber insulation offers durability
• Withstands voltages of 5 to 15kV and is 110 kV BI L-rated
• Includes three 1-piece, single-phase , cold shrink terminations
• IEEE Standard 48 Class 1 Approved for weather-protected applications
5620K Series (Indoor)
Silicone Rubber Indoor Termination Kits with High-K Stress Relief for Tape
Shield, Wire Shield and UniShield® ri-J-:'
Kit Selection Table
I: II
NOTE: Final determination factor is cable insulation diameter.
'-'
Cable Insulation Conductor Size Range (AWG &kcmil)
0.0. Range
Kit Number 5kV100% 5kV133% 8kV133% 15 kV100% 15 kV133%
8kV100%
5621K 0.32 " - 0.46" 8-4 8-6 8
(8,1 -11,7 mm) (10 -16mm') (10 -14 mm~ (10 mm~
5622K 0.44" - 0.65" 2-2/0 4-1/0 6-1
(11 ,2 - 16,5 mm) (35 - 60 mm ~ (22 - 50 mm~ (14 - 38 mm~
5623K 0.56 " - 0.87" 2/0-250 1/0-4/0 1-3/0 4-2/0 4-1
(14,2 - 22,1 mm) (70 - 120 mm~ (60 - 100 mm~ (50 - 80 mm~ (22 - 60 mm~ (22 - 38 mm~
5624K 0.78 " -1 .30" 300-750 250-750 4/0-600 2/0-500 1-350
(19,8 - 33,0 mm) (185 - 325 mm') (70 - 250 mm~ (50 -150 mm~
(150 - 325 mm~ (120 - 300 mm ~
5625K 1.09 " -1 .80 " 600-1500 600-1500 500-1250 500-1250 350-1000
(27,7 - 45,7 mm) (325 - 725 mm ~
(325 - 725 mm~ (300 - 625 mm ~ (300 - 625 mm ~ (185 - 500 mm~
Table 1 o
6020K Series (Indoor)
Termination Kit 6020K Series for 15-25/28 kV
6022K 054007- 125 kV 21.8" 0.64"- 0.90 " 0.80 "-1.20" 2-3/0AWG 4-2/0AWG 2-1 AWG
6023K 49934 125 kV (554 mm) (1 6,3-22,9 mm) (20,3-30,5 mm) (35-80 mm2) (22-60 mm2) (35-38 mm2)
054007- 0.84" - 1.33 " 1.00 "-1.60" 3/0 AWG-500 kcmil
6024K 49935 21.8" (21,3-33,8 mm) (25,4-40,6 mm) (95-250 mm2) 2/0 AWG-350 1 AWG-250
(554 mm)
054007 - 1.1 0"-1.65" 1.30 "-1.90" 500-750 kcmil kc mil kcm il
49936 (27,9-41,9 mm) (33,0-48,3 mm) (300-325 mm ~
(70-150 mm~ (38-125 mm2)
1.30"-1.95" 1.50"-2.40" 750-1750 kcmil
125 kV 21.8" (33,0-49,5 mm) (38,1-61,0 mm) (400-850 mm2) 350 -700 250-600
(554 mm) kcmil kcmil
(180-325 (125-300
mm 2) mm2)
6025K 054007- 125 kV 22.25" 700 -15 00 600-1250
49937 (565 mm) kc mil kcm il
(400-750 (325-625
mm 2) mm2)
