0-T-xxx-3G Series for cables with ground wire - includes
Break-Out Boot (Indoor)
Silicone Rubber Indoor Termination Kits with High-K Stress Relief for
3-Conductor Type "G" (Ground Wire) Copper Tape Shield and Armored Cables
7600-T-3G Series
Termination Application Ranges
(Final determining factor is cable insulation diameter. Listed insulation ranges allow + 0.10" (2,54 mm) for shielding.)
Kit Number Bil Insulation Cable Conductor Size Range (AWG and kcmiQ
(kV) Range 0.0.
5kV SkV 15kV 25/28kV 35kV
Min -Max Max
inch (mm) 100% 133% 100% 133% 100% 133% 100% 133% 100% 133%
7620-T-95-3G 95 0.33 - 0.50 2.20 8-2 6- 4 6- 4 6- 4 - - - - - -
(8,4-12,7) (55,8)
7621-T-95-3G 95 0.50 - 0.70 2.80 1-3/0 2-2/0 2-2/0 2-2/0 - - - - --
(12,7-17,8) (71,1)
7623-T-95-3G 95 0.70 - 0.92 3.30 4/0-350 3/0-350 3/0-350 3/0-350 - - - - --
(17,8-23,4) (83,8)
7624-T-95-3G 95 0.92 - 1.18 3.90 400-500 400-500 400-500 400-500 - - - - --
(23,4-30,0) (99,1)
7625-T-95-3G 95 1.18 - 1.52 4.50 700-1000 700-1000 700-1000 700-1000 - - - - --
(30,0-38,6) (114,3)
7621-T-110-3G 110 0.50 - 0.70 2.80 1-3/0 2-2/0 2-2/0 2-2/0 2-1 - - - --
(12,7-17,8) (71,1)
7622-T-110-3G 110 0.70 - 0.92 3.30 4/0-350 3/0-350 3/0-350 3/0-350 1/0-4/0 2-3/0 - - --
(17,8-23,4) (83,8)
7624-T-110-3G 110 0.92 - 1.18 3.90 400-500 400-500 400-500 400-500 250-350 4/0-350 - - --
(23,4-30,0) (99,1)
7625-T-110-3G 110 1.18 - 1.52 4.50 700-1000 700-1000 700-1000 700-1000 500-750 500-750 - - --
(30,0-38,6) (114,3)
7693-T-150-3G 150 0.70 - 0.92 3.30 4/0-350 3/0-350 3/0-350 3/0-350 1/0-4/0 2-3/0 H/O - --
(17,8-23,4) (83,8)
7694-T-150-3G 150 0.92 -1 .18 3.90 400-500 400-500 400-500 400-500 250-350 4/0-350 2/0-250 1-4/0 1/0-3/0 -
(23,4-30,0) (99,1)
7695-T-150-3G 150 1.18 - 1.52 4.50 700-1000 700-1000 700-1000 700-1000 500-750 500-750 350-500 250-500 4/0-500 1/0-350
(30,0-38,6) (114,3)
7696-T-150-3G 150 1.53 - 1.81 5.40 - - - - - 1000 750 500-750 500-750 350-750
(38,8-46,0) (137,2)
Table 1
