Calport 100 electricity meters tester

ISO 9001 :2000

o Vector chart of three phase power network
o Measure of power network parameters

(class 0,1 or 0,2)
oRange 0,001 ... 10(100)(1 000)(30/300/3000)A

and 10... 480V
o Testing of energy meters
o Voltage, current and power harmonics

analysis
o Powering from measurement network

TECHNICAL PARAMETRS OF THE CALPORT 100

FlIl1l'1iol1 / paramctc, Range

Yoltage I ±O, I% ±0,2%
±O,I%* ±0,2%*
10,00 ...480,OY
40,00 ...480,OY
10,00 .. .40,00Y

Line voltage 17,00 ...832,OY ±O, I% ±0,2%
70,00 ...832,OY ±O, I%* ±0,2%*
17,00 ...70,00Y

Direct current 0,00 I0... 1O,OOOA ±O, I% ±0,2%
0,0500... 10,000A ±O,I%* ±0,2%*
0,00 I0...0,0500A

Current with clamps 100A 0,05 ... IOO,OA ±0,2% ±0,2%
5,00... IOO,OA ±0,2%* ±0,2%*
0,05 ...5,OOA

Current with clamps 1000A 5,0... 1000A 0,5% 0,5%

Current with flex 0 .. .30A/ 3 0 0 A/ 3 0 0 0 A ±I% of range ± I% of range

Power and energy O, I... IOA / 40 ...480Y ±O, I% ±0,2%
direct measure 0,001...0, 1A / 10...40Y ±O, I%* ±0,2%*

Power and energy 5... 100A / 40 ...480Y ±0,2%@cos= 1 ±0,2%@cos= 1
measurement by clamps 0,05 ...5A / 10..40Y ±0,3%@cos=0,5 ±0,3%@cos=0,5
±0,2%*@cos= 1 ±0,2%*@cos= 1
± 0,2%* @ cos=0,5 ± 0,2%* @ cos=0,5

Power and energy 5... IOOOA / 40 .. .480Y 0,5% 0,5%
measurement by clamps

Resolution of energy meter error measurement "e" 0,01% 0,01%

Phase shift 0 ,0 ...± 360 ,0° ±0,4° ±0,4°
direct connection ±0,5° ±0,5°

with clamps

Power factor 0,00...± 1,00 ±0,01 ±0,01
cos and sin

Frequency 45 ,0...65 ,OHz ±O, IHz ±O, IHz

Ambient temperature 0...+40°C operating, -25 ...+60°C transportation

Power supply 85 ..230..265 / 45 ..65Hz / 8YA (12YA with printer)

Dimensions and weight of analyser 270 / 240 / 180 111m 14,5 kg

Dimensions and weight of analyser set 420 / 280 / 37001111 / 8,2 kg

*) of range
**) power and energy errors with respect to apparent power
