AWG70000A Series Product Highlights
The AWG70000A Series is the next generation of the industry-leading Tektronix AWG • Generate wide bandwidth signals at baseband, IF and
portfolio, implementing advanced data rate technologies of up to 50 Gs/s with 10-bit RF frequencies with excellent dynamic range
vertical resolution.
• Accelerate designs and research by generating
waveforms that could not previously be created
• Add impairments to waveforms, eliminating the need
for additional hardware
• Ability to sync multiple units together to increase
transmission bandwidth
Seamlessly import
waveforms from MATLAB,
Excel and other software
packages.
Waveforms captured
on scopes or spectrum
analyzers can be played
back on the AWG.
. ~.: I AWG70002A
. :. AWG70001A 1.5Ks/s to 25 GS/s
10.0 GHz
I 14GHz
22 ps
1.5KS/s to 50 GS/s Up to -80 dBc
20.0GHz 10 bits
14 GHz 1.0 Vp-p (DifferentiaQ
27 ps Standard: 2 GSamples, Optional: 8GSampies
Up to -80 dBc 2 (Differential)
10 bits
1.0 Vp-p (Differential)
Standard: 2 GSamples, Optional: 16GSampies
1 (Differential)
Recommended Accessories Recommended Service Ships with Product
RFXpress R3 3-year Extended Warranty • Keyboard
SerialXpress • Mouse
R5 5-year Extended Warranty • Power Cord
C3 Calibration Service 3 Years
C5 Calibration Service 5 Years
R3DW Repair Service Coverage 3 Years
R5DW Repair Service Coverage 5 Years
Signal Generators Software SerialXpress®Software for the AWG5000, AWG7000,
AWG70000 (SDX1 00)
See page 51 for information
Recreate exact waveforms required for thorough and repeatable
RFXpress®Software for the AWG5000, AWG7000 , design validation , margin/characterization and conformance testing with
AWG70000 (RFX100) SerialXpress and AWG Series signal generators. SerialXpress' easy-to-
use graphical user interface allows for a combination of test signals and
If you are doing RF designs requiring signal modulation, Tektronix' various impairments, including Inter Symbol Interferences (lSI), Duty Cycle
RFXpress software for the AWG Series delivers advanced capabilities to Distortion (DCD), Spread Spectrum Clocking (SSG), Pre-emphasis and
synthesize digitally modulated baseband, IF and RF/microwave signals noise.
supporting a wide range of modulation schemes. RFXpress simplifies
waveform creation. Special options are available for Radar, OFDM, www.tektronix.com/signaLgenerators
S-Parameter, and UWB signals specifically.
www.tektronix.com/rfxpress
