Ģ Cold Shrink QT-II Terminations
3M™ Cold Shrink QT-1I5640 & 5650 Series Termination Kit includes a 4-skirt, 1-piece termination. It ensures a pliable,
tight seal for jacketed concentric neutral power cables. The conjunction of high dielectric-constant material and silicone
rubber insulation allows the termination to withstand voltages up to 15kV.
• Provides a void-free seal to jacketed concentric neutral power cables
• High dielectric-constant material regulates the distribution of electric field stress
• Suitable for outdoor applications
• Termination has 0.64 to 1.12-in insulation 0.0. and 0.93 to 1.35-in cable jacket 0.0.
• Accommodates 2 AWG wire sizes at 15kV
• Molded, silicone rubber insulation offers durability and reduces leakage currents in damp conditions
• Withstands voltages up to 15kV and is 110 kV BIL-rated
• Includes a 4-skirt, 1-piece, cold shrink termination and an SC0001 stem connector
• IEEE Standard 48 Approved for Class 1 terminations
5640 & 5650 Series JCN (Outdoor)
Termination Kit 5640 & 5650 Series
5641-1/0 054007-11964 110 kV 10.0" 0.64"-1.12" 0.93"-1 .35" Yes (1) SCOO1 0 Stem Connector
5641-1/0-MB3 054007-70501 110 kV (254mm) (16,2-28,4 mm) (23,6-34,3 mm) Yes (1) SC001 0 Stem Connector,
5641-2/0 054007-11967 110 kV Yes (1) MB3 Mounting Bracket
5641-2 054007-11965 110 kV 10.0" 0.64"-1.12" 0.93"-1 .35" 1/0AWG Yes (1) SC0020 Stem Connector
5641-22 054007-11968 110 kV (254mm) (16,3-28,4 mm) (23,6-34,3 mm) Yes (1) SC0001 Stem Connector
(1) SC0002 Stem Connector
10.0" 0.64"-1 .12" 0.93"-1 .35" 210AWG No
(254mm) (16,3-28,4 mm) (23,6-34,3 mm) (1) SC0040 Stem Connector
Yes
10.0" 0.64"-1 .12" 0.93"-1 .35" 2AWG
(254mm) (16,3-28,4 mm) (23,6-34,3 mm)
10.0" 0.64"-1 .12" 0.93"-1.35" 2AWG Solid
(254mm) (16,3-28,4 mm) (23,6-34,3 mm) 4AWG
5642 054007-11970 110 kV 10.0" Stranded
(254mm)
0.84"-1.38" 1.19"-1 .72" 3/0 AWG-
5642-4/0 054007-11971 110 kV (21,3-35,1 mm) (30,2-43,6 mm) 350 kcmil
(95-180 mm2)
4/0AWG
5643 054007-11972 110 kV 400-600 kcmil No
(240-325 mm2)
5644 054007-11973 110 kV 11.25" 1.31"-2.10" 1.62"-2.55" 700-1500 No
(286 mm)
(33,3-53,3 mm) (41,2-64,8 mm) kcmil
(400-725 mm2)
