5 kV - Terminations

Ordering Info: Primary Insulation JacketOD Typical Conductor* Maximum
ODRange Range Size Range Lug Width
Kit
Number AWGlKcmil

Inches Inches

7673-S-8(S) 2.01-2.87 2.25-3.45 350-1500
(51,1-72,9) ( 57,2-87,6) (175-725)
(76)

7673-S-8 2.79-3.45 3.00-4.25 1500-3000 4
(70,9-87,6) ( 76,2-108,0) (800-1500) (102)

7673-S-1O(R) 1.30-2.36 1.60-2.85 1/0-350 2
7673-S-INV-1O(R) (33,0-60,0) (40,6-72,4) (50-175) (51)

7673-S-10(S) 2.01-2.87 2.25-3.45 350-1500 3
7673-S- INV-lO(S) (51,1-72,9) ( 57,2-87,6) (175-725) (76)

7673-S-1O 2.79-3.45 3.00-4.25 1500-3000 4

7673-S- INV-lO (70,9-87,6) ( 76,2-108,0) (800-1500) (102)

*Sizing based on 650 mil insulation thickness. For reduced wall cables, use the cables Primary

Insulation 00 and the ranges shown above to determine the correct kit for the application.

Kits with an added suffix may contain materials such as: a lug, mounting bracket, cable clamps,
special instructions, "W8" for additional water blocking of 10 skirt kits or other application specific.
