P. 89
Jl..AMPROBE"
PK-IIO Electrical Test Kit
Amprobe's PK-11 0 Electrical Test Kit offers three electrical testers with testing functions suitable for
a variety of residential applications_The kit includes the AM-420 Digital Multimeter, ST-1028 Socket
Tester with GFCI and VP-1000 Non-Contact Voltage Detector_From identifying voltage presence in
outlets and switches to confirming proper wiring of regu lar and GFCI protected outlets, the PK-110
kit boasts all the features needed to perform quick and safe electrical tests-
AM-420 Digital Multimeter VP-lOOO Non-Conta.ct ST-I02B Socket Tester
Voltage Detector withGFCI
• ACIDC Voltage
• DC current • AC voltage detection • Tests standard and
• Resistance • VISual voltage GFCI outlets
• Audible continuity and diode test
• Battery Test (1.5 V and 9 V) Presence alert • Vermes proper wiring
• Data hold • Detects five different
• Safety rated: CAT II 250 V • Safety rated:
CAT IV 1000 V wiring faults
• CSA listed for safety
FEATURE AM-420 VP-1000 5T·1021
AC Voltage 200.0/250 V 90 Vac - 1000 V AC. 50/60 Hz 110 - 125 V AC. 50 - 60 Hz
DC Voltage 200 mV 2.000/20.00/200.0/250 V
Operating Voltage
INCLUDED ACCESSORIES: User manual
PY-IAVoltage Tester
The PY-1A Voltage pocket-sized voltage tester detects AC and DC voltage ranges on cables, circuit
breakers, wall sockets, junction boxes and other electrical wiring through direct contact.
• Neon lights indicate AC voltage at 120, 240, 277, • Test leads store conveniently in back of unit,
480 V and DC voltage at 160, 330, 380, and 600 V properly spaced for outlet testing.
• For use on energized or non-energized circuits • CSA listed. Safety rated to European Standard
• Simple one hand operation, no buttons or 61010-01 Category III 600 V
setup required
PY-1A
LAN-I LAN Tester
With quick go/no-go tests, you can find opens, shorts and miswired cable installations. You can
either step through the test cable one at a time, or let the unit automatically pulse through the
pin-outs and display the results.
• Remote termination module tests installed cable • Buzzer sound warns for error condition in cable
on wall plate or patch panels • Two sets of LED lights indicate source and test
• Maximum line length: 328 yards (300 m)
• Perform loopback or remote tests
FEATURE LAN-1
Cable Types Tested
Continuity Maximum Length 10/100 base-T; 10 base-2; RJ45; AT&T 258A;
EIA 1TlA 568A1568B; Token Ring
> 300 meters
Connector Types RJ45. BNC
INCLUDED ACCESSORIES: User manual. batteries (installed). remote terminator, RJ4 5 to fema le BNC
CE c~ls &cable, RJ45 to male BNC cable, RJ45 to RJ45 cable, Female BNC to Female BNC cable
LAN-1
