P. 598
ulating and Splicing - Rubber Tapes
Scotch® Rubber Splicing Tape 23
Scotch® Rubber Splicing Tape 23 is a highly conformable, self-fusing Ethylene Propylene Rubber (EPR), high-insulating voltage tape. Scotch Tape 23 has a
"snakeskin" liner that is easily removed as the tape is applied. This product can be used forlow and high-voltage (through 69 kV) applications.
UnerlLinerless Uner fi§"$3
Material Ethylene Propylene Rubber (EPR)
Premium
Tape Grade Insulating and Splicing
Tape Type
Up to 194°F (90°C)
Operating Temperature
Short Term Overload Service 266°F (130°C)
RoHS 2011/65/EU Yes
ASTM D-4388 type 1, 2 &3 ; HH+
Specifications 38258
3MTM Linerless Splicing Compound 2242
3MTM Unerless Splicing Compound 2242 is a multi-purpose rubber insulating tape designed for use in splicing and terminating wires and cables rated up to
194°F (90°C). 3MTMUnerless Splicing Compound 2242 is a highly conformable, linerless Ethylene Propylene Rubber-based tape.
UnerlLinerless Unerless
Self-fusing Ethylene Propylene Rubber
Material (EPR)
Tape Grade Premium
Tape Type Insulating and Splicing
0-194OF (-18-90°C)
Operating Temperature
RoHS 2011/65/EU Yes
ASTM D-4388 type 1, 2 &3; HH+
Specifications 553C
Order No. UPC Color Length Width Thickness Breaking Strength Rolls per Cartnn Rolls per case
2242-314X15FT 054007-06165 Black 15' 0.75" 30 mil 7.5 Ibs/in 24
2242-1-1/2X15FT 054007-41323 Black 15' 1.50" 30 mil 7.5 Ibs/in 12
2242-2X15FT 054007-43251 Black 15' 2.00" 30 mil 7.5 Ibs/in 8
Scotch® Self-Fusing Silicone Rubber Electrical Tape 70
Scotch® Self-Fusing Silicone Rubber Electrical Tape 70 is a high-temperature, arc- and track-resistant tape composed of self-fusing, inorganic silicone
rubber with an easy-tear and easy-strip liner. Scotch® Self-Fusing Silicone Rubber Electrical Tape 70 can be used as base tape layer to cleanly reenter
connections.
Material Inorganic Silicone Rubber
Tape Grade Premium
Insulating and Splicing
Tape Type Up to 356°F (180°C)
Operating Temperature Yes
RoHS 2011/65IEU AA-59163 Class-I Type I; ASTM D-
1000-76; ASTM D-495-71
Specifications
592 www.tech-equipments.comlsales@tech-equipments.com
