P. 629
M ResinSplice Kits
3MTM Scotchcast™ Wye Resin Splice Kit 90-B1
3MTM Scotchcast™ Wye ResinSplice Kit 90-B1 insulates and moisture-sealswye splices made with the split-bolt type connectors on cables rated through
1 kV.
Each kit makes one splice. Connectors must be ordered separately.
Voltage 1000 Vor less Single Conductor Cable
Number of Conductors
Single; Multiple
Cable/Shielding Type Single Conductor Cable, Multiple
Splice Type Conductor Cable
Applications Resin
Insulation and protection of wye
RoHS 201 1/65/EU splices made with split bolt connectors
on cable rated to 1000 V.
Yes
3MTM Scotchcast™ Flexible Power Cable Tap Splice Kit 82-BF1
3MTM Scotchcast™ Splice Kit 82-BF1 is for tap splices on non-shielded portable power cables and cords with copper conductors rated up to 1 kV. lt can be
used on single- conductor or multiple-conductor cables using a compression (crimp) "Cn tap connector.
The 82-BF1 molds are removable and reusable. The 82-BF1 splice kit creates a permanent splice as recognized by the Mine Safety and Health
Administration (07-KA060002-MSHA).
Each kit makes one splice.
* Base selection on cable 0.0. range.
Voltage 1000 Vor less Single Conductor Cable
No. of Conductors
Cable/Shielding Type Multiple (600 V), Single(1000 V)
Non-Shielded Portable Power Cables
Splice Type and Cords
Applications Resin
Making tap splices on non-shielded
RoHS 201 1/65/EU portable power cables and cords rated
to 1000 V.
Yes
www.tech-equipments.comlsales@tech-equipments.com 623
