AMPROBE$
Navigator CAT IV Power Quality
Clamp Meters
These power qual ity clamp meters measure power and power factor, tota l ha rmonic d istortion,
individual harmonics, as well as ACJDC voltage, current, capacitance, inrush current analysis,
and phase sequence. The low pass f ilter enables voltage and cu rrent measurement on
variable frequency drives. The Navigator'· joy stick allows quick selection of the numerous
measurement featu res on the large LCD display. Built for rugged industrial environments w it h
CAT IV 600 VlCAT 111 1000 V safety rating.
• THD {total harmonic distortion} and individual • MAXIMIN and smart data hold
harmonics 1-25
• Peak hold
• Power (KW) and power factor {0-1} indicates • Auto flashl ight when clamping
electrical usage and system efficiency • Large backlit display w ith analog bar graph
• Overmold body absorbs shock - drop-proof
• True-RM5 provides accuracy and dependability
to 4 ft {1.2 m}
• Low-pass filter for variable frequency drives
• Inrush current measurement for motors • Safety Rated CAT IV 600 V
• Phase rotation indication
Temperature -50°F - 1832°F -50'F - 1832°F +/- (1% rdg + 1°C)
(-50°C - 1000°C) (- 50'C - 1000°C)
THO
(Total Harmonics 0.1% - 100.0% +/- (3.0% rdg + 10 LSD)
Disto n i on)
Ind iv idual 1 - 25
Harmonics
Power
INCLUDED ACCESSORIES: Test leads, user man ual, batteries (installed),
thermocouple (ACD-51NAV and ACDC-54NAV only)
Navigate Through Any Job ACD-50NAV ACD-51NAV ACDC-52NAV ACDC-54NAV
Job Function Applications Model
Industrial Motor Testing. Use inrush current to test motors capacitance to check start up capacitors ACDC-S2NAV
Electricians and phase rotation to measure three-phase systems ACDC-S4NAV
Power Quality. Quickly determine the efficiency of an electrical system by measu ring
power factor and worki ng power mea surements. Check for harmful harmonics while you
perform daily system checks
Transformers. The Navigator'· Clamp is the ideal tool for maintenance and installation of
transformers and advanced equipment
Facilities System Monitoring. Assess and monitor the condition of various systems and advanced ACD-SONAV
Maintenance equipment such as power quality analyzers
Performance Testing. Verify system efficiency and quickly troubleshoot issues to
minimize costly downtime by performing load studies, motor testing system checks
HVAC Technicians System Monitoring. Maintain large, complex HVAC systems in factories, data centers, ACD-S1NAV
hospitals and commercial buildings
Performance Testing. Best tool for techn icians who need the following critical
measurements during HVAC system checks and repa irs:
• Capacitance f or checking startup capaci t ors
• Micro Amps for the verification of the f lame sensors
• Temperature for checking cooling/heating pe rformance
• Inrush current for verification of the compressor motor
• Low-pass f ilter t o allow measurement of the vari able frequency drives
