Page 82 - techequipmentscatalogue2016
P. 82
AMPROBE$
Swiver Clamp Meters
Get fast and easy testing for HVAC and electrical applications. See measurements in tight or
inconvenient spaces with the patented 180-degree rotating head design of Amprobe's Swivel '·
Clamp Meters. The slim jaw puts all features within reach for one-handed operation.
• 1So-degree rotating head • Auto ranging for quick checks
• VolTecf" non-contact voltage detection • Manual ranging for precise measurements
• Audible continuity • Data hold
180· degree
rotating head
Accommodates Up to 1.18" (30 mm) in diameter
Conductors
INCLUDED ACCESSORIES: Test leads, battery (installed), user ma nual,
ca rrying case, K-type t hermocouple (ACD-23SW only)
ACD-IO PLUS Clcunp Multimeter FOR: ACD-20SW, ACD-23SW.
ACD-10 PLUS. ACD-14PLUS and
with Uniquely Thin Jaws ACD-14 TRMS-PLUS
With thinner jaws than standard clamp multimeters (only 0.4"/10 mm thick), the ACD-10 PLUS
and ACD-14 PLUS allow access to tight measurement areas and still accommodate conductors
up to 1"/25 mm.
ACD-14 PLUS and ACD-14 TRMS-PLUS TL35B ELS2A
Test Leads AC Line
Sp litter
Dual Display Digital Clamp Multimeters
The professional's choice for both HVAC and electrical applications with a complete set of
measurement features including dual displays that allow you to view amperage and voltage
measurements simultaneously.
• Continuity buzzer • Microamps for testing
• Hold and maximum reading functions flame sensors (ACD-14 PLUS only)
• Auto ranging • Diode test (ACD-14 PLUS and
• Auto power off and low battery indication ACD-14 TRMS-PLUS only)
• Rubber over-molded case
• Frequency is measured by either jaws or test • True-RMS for more accurate readings in noisy
environments (ACD-14 TRMS-PLUS only)
leads (ACD-10 PLUS only)
Conductors up to 1.0" (25 mm) in diameter
ACD-10 PLUS
INCLUDED ACCESSORIES: Test leads, battery (installed), soft carrying pouch, K-type ACD-14 TRM-PLUS
thermoco uple w ith banana plug (ACD-14 PLUS and ACD- 14 TRMS-PLUS only), user manual
I
